Background

Context

There are no engineered (genetically modified) crops grown in Ireland and a nominal hectarage is grown in the EU. Outside of the EU though, the area of engineered crops has increased year-on-year since they were first grown in the USA in 1996 with the cultivation of an  insect resistant maize variety. Over the 20 years since then, more and more traits have been introduced into a wider range of crop species.

Winter Wheat

How do you genetically engineer a crop?

An engineered crop is generated by the transfer of a gene (or genes) of interest from one species into another (e.g. wild wheat into commercial wheat). In the case of the insect resistant maize varieties, they were generated by transferring a gene from a soil inhabiting bacterium Bacillus thurigensis into commercial maize varieties so that the new and improved variety had all the high value traits the farmer needed plus the added trait of insect resistance.

The method to transfer the gene(s) into the target plant cell has in nearly all cases relied on the use of a soil-derived bacterium called Agrobacterium tumefaciens. A naturally occurring soil-borne bacterium, A. tumefaciens is more known for its capacity to call crown gall disease on trees.

Agrobacterium Crown Gall tree disease

Image: Crown gall infection on mature tree

Through evolution A. tumefaciens has developed the capacity to naturally engineer plant cells by transferring its own genes into plant cells, which then in turn produce chemical compounds that benefit the bacterium. In the 1980’s scientists discovered that A. tumefaciens can in fact be manipulated to deliver pretty much any gene of interest. Since then, the use of this bacterium has been heavily researched and as a result due to the commercial significance of the global trade in engineered seeds the patent landscape around the use of Agrobacterium Mediated Transformation (AMT) has become very complex.

The Breakthrough

Following the ground-breaking work completed by the Australian CAMBIA group, we set about trying to identify an alternative bacterium that could genetically engineer a plant cell, which was not closely related to A. tumefaciens. The reasoning behind this strategy was that such a strain (if it existed) could have the potential to bypass existing patents on the use of AMT and hence this would facilitate those public/private researchers around the world who wish to develop regionally important cultivars suited to local farmer’s needs. After several months of investigations one such strain was identified.

Entitled Ensifer adhaerens strain OV14, we now know based on published research that this strain can engineer rice, potato, tobacco, oilseed rape and cassava and the list is constantly expanding. As a result, what started out as a ‘look-see’ basic research project has developed into an exciting multi-disciplinary research programme that has established linkages and collaborations with researchers across the world.

The Advantages

Through these collaborations we are starting to 'lift the lid' on the processes that drive EMT. We have successfully sequenced and annotated the genome of E. adhaerens strain OV14  while we also have optimised the microbiological conditions in support of EMT. More recently the regulatory  'freedom-to-operate' around EMT has been clarified by USDA APHIS, who deemed E. adhaerens strain OV14 to be a non-plant pest. Combined with our active research programme, we believe the utility of EMT will continue to expand as user number increases.







Research

We are actively researching the processes underlying EMT. After publishing the ability of E. adhaerens OV14 to engineer potato in 2012 we have been focussed on addressing the questions that the community have been asking, including;

  • What genetic machinery does EMT rely on?
  • How related is E. adhaerens OV14 to A. tumefaciens, if at all?
  • How easy/hard is EMT ?
  • What is the host range of E. adhaerens strain OV14 ?
  • Does EMT suffer from genotype dependency to the degree AMT does ?
  • How do plants respond to E. adhaerens OV14?
  • What is the regulatory requirement associated with EMT?

To date, we have sequenced and annotated the genome of E. adhaerens OV14 and compared it against that of A. tumefaciens C58. This has provided a tremendous insight into what E. adhaerens OV14 has and what it doesn’t have regarding its genetic machinery. Additionally, this SFI funded project has allowed us to specifically calculate how related E. adhaerens OV14 is to A. tumefaciens. The data from this study is a critical resource for the EMT programme, and the resulting paper reached 'highly accessed' status within two weeks of publication.

Work with our international partners has already confirmed the utility of EMT on rice and oilseed rape (canola) and we are currently working to determine how efficient EMT is on barley, wheat, soybean and maize.

Separately, we recently characterised  the antibiotic profile of E. adhaerens OV14, which is critically important for current and future users of EMT who may require varying recipes of antibiotics to achieve their own work goals.

The primary focus at the moment is on characterising how a plant cell responds to EMT and then in parallel how does E. adhaerens OV14 actually achieve EMT. This is something that is not known and we are eager to find out.

Licensing Opportunities

Licensing

The initial goal of this programme was to expand the genetic engineering 'toolbox' to identify an alternative plant engineering tool for the plant science community. Since identifying Ensifer adhaerens Ov14 as a strain with the capacity to engineer both monocot and dicot genomes we have continued to develop the potential of EMT. In parallel and in collaboration with the Teagasc Technology Office we have generated a flexible licensing strategy that seeks to maximise the number of EMT users while ensuring users gain access to our latest developments in EMT.

The EMT technology is covered in the USA under US 9,365,858 B2 and freedom-to-operate with EMT from a regulatory perspective has been recently clarified by the USDA APHIS who confirmed the non-plant pest status of Ensifer adhaerens Ov14 .

We currently have 18 partners around the world evaluating EMT for their own specific purposes. If you wish to join the list please get in contact and we will explain our policies around ease of use. If you wish to initiate a research evaluation we have a range of flexible options available to suit both private and public institutions.

Team and Funding

Current Members

Profile image of Dr. Ewen Mullins

Dr. Ewen Mullins

Programme Leader

Profile image of Evelyn Zuniga-Soto

Evelyn Zuniga-Soto

PhD Student

Profile image of Ashok Govindan

Ashok Govindan

PhD Student

Profile image of Dr. Dheeraj Rathore

Dr. Dheeraj Rathore

Contract Researcher

Profile image of Prof. Fiona Doohan

Prof. Fiona Doohan

Collaborating Partner
